Number of inputs5Power supplyvia UP contactsAuxiliary power currentU_P contacts: dependent on the potentiometers, max. 125 mATechnologyratiometric potentiometer evaluation with supply, 3-wireDistributed clocksyesFeed voltage potentiometertyp. 10 V ±10%Internal resistance>> 100 kΩ to wiper connectionInput filter limit frequencytyp. -3 dB at 3 kHz and potentiometer 50 kΩSensor typespotentiometer 300 Ω…50 kΩOutput currentmax. 0.3 A total supply current for the potentiometersWiring fail indicationyesConversion timetyp. 300…700 µs, dependent on settings, default setting: approx. 500 µs (5 channels, filter deactivated)Resolution16 bit (incl. sign)Measurement error/uncertainty< ±0.5% (relative to full scale value)Electrical isolation500 V (E-bus/field potential)Current consumption E-bustyp. 80 mASpecial featuresopen-circuit recognition, supply monitoring, activatable filters, simultaneous measurement of the channelsWeightapprox. 30 gOperating/storage temperature0…+55°C/-25…+85°CRelative humidity95%, no condensationEMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27Protect. rating/installation pos.IP20/see documentationApprovals/markingsCE
